Customizable Movable Partition Wall with 68CM Thickness and 800N Sealing Power Operable Wall System

Customizable Movable Partition Wall with 68CM Thickness and 800N Sealing Power Operable Wall System

Tên thương hiệu: AE
Số mẫu: AE65
MOQ: 10 mét vuông
giá bán: USD 79-108 per square meter
Điều khoản thanh toán: T/T, L/C, Western Union
Khả năng cung cấp: 1000 mét vuông mỗi tháng
Thông tin chi tiết
Nguồn gốc:
Quảng Đông, Trung Quốc
Chứng nhận:
ISO9001 SGS CANS
Loạt:
Tường ngăn di động AE65
Tùy chọn hoàn thiện:
Vật liệu do khách hàng cung cấp
Ứng dụng:
Nhà hàng, Phòng họp
độ dày:
68cm
Xếp hạng STC:
42-56dB
Kích thước:
Tùy chỉnh (Chiều cao: lên đến 4,5M, Chiều rộng mỗi tấm: lên đến 1,2M)
Tên:
vách ngăn di động
chi tiết đóng gói:
Lớp bọt và bìa cứng cứng với vỏ gỗ dán hoặc pallet thép
Làm nổi bật:

68CM Thickness Movable Partition Wall

,

800N Sealing Power Operable Wall System

,

40N/m Magnetic Attraction Room Divider

Mô tả sản phẩm
Customizable Movable Partition Wall Office Operable Wall Systems

AE operable partitions are a series of panels suspended from tracks with high quality, functionality and variability for room-dividing and multifunctional layout configuration.

Key Features
  • German Partition Technology Global Professional Space Solutions
  • Highly competitive prices
  • Good quality control
  • Smooth communication
  • State-of-art technology products
  • Effective OEM&ODM service
Roller Options & Features
  • Dupont POM roller
  • 304 stainless steel heavy duty roller with safety device & CNC machining
  • Unique and patented wheel surface and shape for easy operation
Panel Options & Features
  • Thickness: 68mm, 89mm & 105mm options
  • Wide variety of acoustical and decorative finishes available
  • 6061-T6 profile with Q235 steel frame for superior durability
  • Top & bottom jack lifting mechanism seal with 800N power
  • Magnetic seal in concave & convex profile with 40N/m magnetic attraction
Technical Specifications
Series Element Thickness (mm) Element Width (mm)* Clear Height (mm)* Construction Panel Fixing Element Interconnection
AE65 68 600/1,250 2,000/4,500 Aluminium-steel Freely oscillating Aluminium profile with magnetic strip and sealing lips
AE85 89 600/1,250 2,000/5,500 Aluminium-steel Freely oscillating Aluminium profile with magnetic strip and sealing lips
AE100 105 600/1,250 2,000/18,000 Aluminium-steel Freely oscillating Aluminium profile with magnetic strip and sealing lips
Technical Details
  • Weighted sound reduction value: 52/56 dB (Rw) per GB/T19889.3-2005
  • Positive and frictional locking of vertical element connections
  • Convex-concave profile form with magnetic strip attraction force of 40 N/m
* Larger widths possible on application. Provisional details regarding element heights/widths require consultation with Design Department.
